745 XL |
|
Bildergalerie |
|||||||||
| Baujahre (Built Years) |
1981-1990 |  |
 |
    |
|||||||
| Stück (Built Units) |
5066 | ||||||||||
| Motor (Engine) |
IHC D-239 | ||||||||||
| Art / Zyl. (Type/Cylinder) |
4-Zyl.-Diesel | ||||||||||
| Hubraum (Displacement) |
3911 cm³ | ||||||||||
| U/min. (rpm) |
2300 |   |
|||||||||
| PS (Engine-HP) |
72 |  |
 |
||||||||
| Getriebe (Transmission) |
16+8 | ||||||||||
| Bereifung (Tyres front/rear) |
7.50-18 / 16.9-34 (2 WD) 12.4-24 / 16.9-34 (4 WD) |
||||||||||
| Gewicht (Weight) |
3430 - 3930 kg | ||||||||||
| Seriennummer (Serial-No´s) |
D030230 D001000 - 005767 D030230 D030000 - 030536 (40 km/h) |
||||||||||
| Die Montage des 745
XLwurde 1990 zum IH-Werk Doncaster / GB verlagert und
dort bis 1994 fortgeführt. 1990 assembly of the 745 XL tractor was transferred to IH works Doncaster / GB, 745 XLwas built till 1993. |
|||||||||||
