533 |
|
Bildergalerie |
|||||||||
| Baujahre (Built Years) |
1975-1990 |  |
 |
    |
|||||||
| Stück (Built Units) |
17113 | ||||||||||
| Motor (Engine) |
IHC D-155 | ||||||||||
| Art / Zyl. (Type/Cylinder) |
3-Zyl.-Diesel | ||||||||||
| Hubraum (Displacement) |
2536 cm³ | ||||||||||
| U/min. (rpm) |
2200 |   |
|||||||||
| PS (Engine-HP) |
45 |  |
 |
||||||||
| Getriebe (Transmission) |
8+4 Synchron | ||||||||||
| Bereifung (Tyres front/rear) |
6.50-16 / 13-28 (2 WD) 10.5-18 / 12.4R32 (4 WD) |
||||||||||
| Gewicht (Weight) |
2240 kg (2 WD +/- Kabine) 2770 kg (4 WD +/- Kabine) |
||||||||||
| Seriennummer (Serial-No´s) |
D030350 D001000 - D030350 D018645 |
||||||||||
| Ab 1990 wurde der
533 als Typ 540 bis 1993 im britischen IH-Werk Doncaster
gebaut. Was built from 1990 - 1993 at IH Doncaster works as type 540. |
|||||||||||
| © matbush Juni 2011 |
